Description
The Context Plus Red Warning Light with Sounder is a compact yet powerful audio-visual alarm device designed to provide immediate and effective alerts in emergency situations. Engineered with a high-impact polycarbonate lens and IP65-rated protection, it is suitable for both indoor and outdoor environments, delivering reliable performance even in harsh conditions.
With a high sound output of 103 dB(A) and wide-angle sound distribution, this unit ensures that critical alerts are heard clearly across large or noisy areas. Its low current consumption and versatile voltage compatibility make it energy-efficient and easy to integrate with fire alarm, security, and hazard warning systems.
Available in multiple tone versions and featuring locally adjustable sound levels, the Context Plus Red Warning Light provides unmatched flexibility for different applications. The built-in override function allows for a seamless switch to a second-stage alarm tone, ensuring prompt and unmistakable responses during escalating emergencies.
Key Features & Benefits
-
🔊 High Sound Output – Powerful 103 dB(A) audio alert, ensuring audibility in noisy and open environments.
-
⚡ Low Current Consumption – Consumes only 13mA at 24V DC, reducing strain on power supply systems.
-
📡 Wide Angle Sound Distribution – Even sound coverage for maximum effectiveness in all directions.
-
🔋 Flexible Voltage Range –
-
CP400SR: 8–28V DC (optimized for 12V & 24V systems)
-
CP450SER: 20–28V DC (optimized for 24V systems)
-
-
🎚️ Adjustable Output Levels – Locally controllable volume settings to match specific site requirements.
-
🎶 Multiple Tone Options – Available in 4 distinct tone versions to suit fire, hazard, or general alarm needs.
-
🔄 Override Function – A third-wire input enables switching to a second-stage alarm tone for escalated alerts.
-
💧 IP65 Protection Rating – Resistant to dust and low-pressure water jets, suitable for harsh indoor/outdoor environments.
-
🛡️ Durable Polycarbonate Lens – Strong, flame-retardant, and impact-resistant for long service life.
-
🌍 Standards Compliance – Fully compliant with EN54 standards, ensuring global reliability and safety.
Specifications
-
Sound Output: 103 dB(A)
-
Current Consumption: 13 mA @ 24V DC
-
Operating Voltage: CP400SR (8–28V DC), CP450SER (20–28V DC)
-
Protection Rating: IP65
-
Dimensions (H x W x D): 100 x 95 x 99 mm
-
Weight: Approx. 160g – 182g
-
Housing Material: Flame-retardant polycarbonate (red lens)
Applications
✔️ Fire Alarm Systems – Reliable audio-visual alerts in case of fire emergencies.
✔️ Security Systems – Effective intrusion and unauthorized access warnings.
✔️ Hazard & Safety Alerts – Suitable for industrial plants, warehouses, and construction sites.
✔️ Public & Commercial Buildings – Offices, hospitals, schools, malls, hotels, and transport hubs.
✔️ Indoor & Outdoor Environments – Thanks to its IP65 protection and robust design.
🔹 The Context Plus Red Warning Light combines powerful performance, durable construction, and compliance with international standards, making it a trusted choice for any fire, security, or emergency alarm system.
