Description
The Auto Fire Safety Water Sprinkler – Upright is a state-of-the-art firefighting device designed to provide automatic, fast, and reliable fire suppression in a wide range of environments. Built with precision engineering and certified safety standards, this sprinkler is a vital part of any modern fire protection system.
At its core, the sprinkler uses a highly sensitive glass bulb (available in 5 mm Standard Response or 3 mm Quick Response) that reacts instantly when exposed to elevated temperatures of 68°C (155°F) or 79°C (175°F). Upon reaching this activation point, the bulb shatters, releasing a valve mechanism that allows water to discharge and spread in a controlled spray pattern to suppress the fire. The upright configuration ensures effective water distribution even in spaces with overhead obstructions such as beams, ducts, or high storage racks, making it ideal for warehouses, manufacturing facilities, chemical plants, parking structures, and large commercial buildings.
Constructed from durable Brass ASTM B36, this sprinkler offers exceptional resistance against corrosion and wear, guaranteeing a long service life even in harsh industrial conditions. Each sprinkler is UL Listed and undergoes rigorous testing up to 500 PSI, while being certified for safe operation at a maximum working pressure of 175 PSI. This ensures not only compliance with global fire safety standards but also unmatched reliability during emergencies.
The 1/2” BSPT / NPT connection allows easy integration into existing fire suppression piping networks. Its compact yet robust design makes it simple to install, maintain, and replace without requiring complex tools. Additionally, the sprinkler is manufactured in Taiwan, known for its advanced fire safety technology, ensuring consistent quality and international reliability.
Beyond its technical specifications, this upright sprinkler provides peace of mind, knowing that in the event of a fire, it will activate automatically and immediately, helping save lives, minimize property damage, and reduce downtime in critical facilities. Its affordable yet high-performance design makes it a preferred choice for fire protection engineers, contractors, and facility managers worldwide.
Key Features & Specifications:
-
Type: Upright Automatic Fire Sprinkler
-
Activation Element: 5 mm glass bulb (Standard Response) / 3 mm glass bulb (Quick Response)
-
Temperature Ratings: 68°C (155°F) & 79°C (175°F)
-
Connection Size: 1/2″ BSPT / NPT thread
-
Material: High-strength Brass ASTM B36 body for durability
-
Pressure Ratings:
-
Maximum working pressure: 175 PSI
-
Tested pressure: 500 PSI (100% factory tested)
-
-
Design: Upright discharge for areas with overhead obstructions
-
Certification: UL Listed for international compliance
-
Finish: Polished brass with clear, visible glass bulb
-
Origin: Made in Taiwan
Applications:
-
Industrial Facilities: Manufacturing plants, chemical storage areas, refineries, and workshops
-
Commercial Buildings: Shopping malls, offices, hotels, and residential high-rises
-
Warehouses & Logistics: High-rack storage, distribution centers, and cold storage facilities
-
Parking Structures: Multi-level car parks where fires can spread rapidly
-
Public Spaces: Airports, railway stations, and hospitals for comprehensive fire safety
The Auto Fire Safety Upright Sprinkler is more than just equipment—it is a lifesaving investment that ensures quick response, maximum coverage, and reliable performance in any fire emergency. With international certification, robust construction, and cost-effective deployment, it stands as one of the best fire sprinkler solutions available for professional fire protection systems.
